1
Desperately Seeking…
a lightweight Perl web framework
  • Peter Edwards
2
Introduction
  • Peter Edwards ~ background
3
Aims
  • Learn what frameworks are out there
  • Technical considerations
  • Business tools for decision-making


  • Audience: What is your background and interest?
4
Topics
  • Define the problem
  • Example requirements
  • Attributes of frameworks
  • Business decision making tools
  • Architecture
  • Application components
  • Perl application frameworks
  • Roll your own
  • Summary
5
Define the Problem
  • Why do you need a web app?
  • What functionality / how complex?
    no. screens, other features, e.g. search engine, integration to other apps/components/company infrastructure, server platform
  • Business setting
    Project length, size; Developer expertise, skill sets; Integration to network, database type, existing frameworks e.g. ADS authentication; Capacity plan - no. of users and required performance
6
Example
  • http://merlinfootball.com
  • Components
    Flash front end, sending XML transactions to
    Perl back end
    Perl XHTML admin system
  • Elements
    Huge volume of users and transactions
    Streaming video
    Picture upload and approval to gallery
    FAQ submission, approval and editing into FAQ list
7
Attributes of Frameworks
  • Size -> complexity
  • Learning curve
  • Vertical vs. horizontal
  • Functionality, flexibility
  • Monotheistic/"One True Way" vs. agnostic
  • Increased power, reduced performance
  • Cost of testing new code = 50% of time
  • By extension  DRY  KISS
8
Business Decision Making Tools
  • The point of business
    Increased shareholder value - cash
  • William of Occam, 14th century logician and Franciscan friar
    entia non sunt multiplicanda praeter necessitatem
    entities should not be multiplied beyond necessity
    "All things being equal, the simplest solution tends to be the best one.“
    It often happens that the best explanation is much more complicated than the simplest possible explanation because it requires fewer assumptions.
  • Pareto Principle, by Joseph M. Juran named after Vilfredo Pareto, Italian economist
    "for many phenomena, 80% of the consequences stem from 20% of the causes“

    -- en.wikipedia.org
  • Cost Benefit Analysis
    Estimate days for development
    Estimate hidden costs and benefits e.g. of more stable framework
    Cost comparison -> decision
    Perfection vs. pragmatism
9
Architecture I
  • Web Protocol
    HTTP request/response
    URI, REST, URL parameters  http://server.com/client/view/FRED?view=xml&tabs=all
    Web 2.0, AJAX
  • Web Server
    Apache, IIS, lighttpd
    CGI/mod_perl, FastCGI
  • Controller Processing
    Apache registry style stacked phase handlers
    MVC Model View Controller
    Single entry point vs. separate CGI


10
Architecture II
  • Session
    CGI::Session
    Apache::Session
    Catalyst::Plugin::Session -> Cache::FastMMap
  • Security
    Authentication
    Group permission roles
    HTML field and SQL field encoding
  • Database layer
    Direct  DBI
    Simple  Class::DBI
    ORM Object Relational Mapper  DBIx::Class Rose::DB
    Performance considerations - DBI 10-100x faster
    Data object attributes - data dictionary - screen dictionary


11
Architecture III
  • Templates
    Template::Toolkit (TT2)
    variable merge, not too complex,
    encourages using Perl in app modules
    HTML::Mason – inline code
    Personal preference; understandable by Web designers
    XHTML, accessibility, internationalisation Locale::Maketext
    Form handling, CRUD from db object, validation  Data::FormValidator
    Rich components http://script.aculo.us/ http://dojotoolkit.org/
  • Testing
    module unit test, business data object tests, Javascript/browser compatability checks
    Test::More  Test::WWW::Mechanize  Test::WWW::Selenium
12
Application Components
  • Pre-built components
    save time in short term on testing; may cost more long term; integration costs
    PHP::Session
  • Language Repository Template Component
    Perl CPAN TT2 Bricolage
    PHP PEAR Smarty CMSMS
    Python Built-in Clearsilver Trac
13
Perl Application Frameworks
  • CGI::Application + CGI::Session  lightweight, easy to use, reliable, full control, open
  • Watch out for CGI::Builder, based on CGI::App but used to have Makefile.PL that downloaded and eval'd code, also bizarre "Perlish" coding style
    ; use 5.006_001
    ; use Carp
    ; $Carp::Internal{+__PACKAGE__}++
    ; $Carp::Internal{__PACKAGE__.'::_'}++    ; use IO::Util
  • CGI::Framework
    fixed - glue between HTML::Template, CGI::Session, CGI, Locale::Maketext  last release 11-Oct-2005
  • Jifty  one true way: database mapper, template, web services, AJAX toolkit, handlers for FastCGI  continuations, form-based dispatch  "Jifty is the only web application framework that comes with a pony“
  • Gantry + Bigtop  Apache/mod_perl, MVC  Bigtop - web application data language processor, app generator
  • OpenInteract + SPOPS  Complex, slow, powerful, CMS-oriented permissions  last release 18-Mar-2005
  • Catalyst
    agnostic, MVC, complex, magic, powerful, slow (third time in NEXT/C3 OO extension), well tested  Works well with DBIx::Class and TT2; can also use Class:DBI, HTML::Mason  Many plugins for auth, XML etc.
  • Maypole (ancestor of Catalyst)  similar approach  Class::DBI, TT2
14
Roll Your Own
  • "Not invented here" syndrome, AKA submitting a module to CPAN with "Lite" or "Plus" in the name.
  • Can base on CGI::Application + CGI::Session
  • Or write one yourself. Easier than you'd think. Here's one written in a week, not pretty but delivered a project delivered fast and on time: http://perl.dragonstaff.co.uk/app.zip
15
Summary
  • Processes and decision making
  • requirements
  • business context
  • CBA decision basis
  • technical considerations, architecture, constraints and features
  • application components
  • Perl application frameworks


16
Where to Get More Information

  • CPAN http://search.cpan.org
  • Books


  • Any Questions


  • These slides are at http://perl.dragonstaff.co.uk/
